200T Pressure High Automatic Punch Press for Max 20mm Thickness Gypsum Board Perforation Machine

200T Pressure High Automatic Punch Press for Max 20mm Thickness Gypsum Board Perforation Machine

ব্র্যান্ড নাম: LVJOE
মডেল নম্বর: LV-CK01
MOQ.: 1 সেট
মূল্য: US $20000-80000
অর্থ প্রদানের শর্তাবলী: টি/টি, এল/সি
সরবরাহের ক্ষমতা: প্রতি বছর 50 সেট
বিস্তারিত তথ্য
উৎপত্তি স্থল:
চীন
সাক্ষ্যদান:
ISO CE
পণ্যের নাম:
জিপসাম বোর্ডের জন্য সিএনসি স্বয়ংক্রিয় মেকানিক্যাল মোটর পাঞ্চিং মেশিনের জন্য বাণিজ্যিক প্রকৌশল পাঞ্
কীওয়ার্ড:
MDF বোর্ড হোল ড্রিলিং মেশিন
চাপ:
80 টি, 160 টি, 200 টি
ব্যবহার:
জিপসাম বোর্ড, এমডিএফ, এইচপিএল, ফাইবার সিমেন্ট বোর্ডের ছিদ্র
গর্ত:
রাউন্ড, স্কোয়ার
স্বয়ংক্রিয় স্তর:
উচ্চ স্বয়ংক্রিয়
পুরুত্ব:
সর্বোচ্চ 20 মিমি
ওয়ারেন্টি:
1 বছর
মূল উপাদান:
অ্যালার্ম লক
যন্ত্রপাতি পরীক্ষার রিপোর্ট:
প্রদান করা হয়েছে
প্যাকেজিং বিবরণ:
পিই ফিল্ম মোড়ানো
যোগানের ক্ষমতা:
প্রতি বছর 50 সেট
পণ্যের বর্ণনা
Commercial Engineering Punch Press
CNC Automatic Mechanical Motor Punching Machine For Gypsum Board
Product Overview
High-performance gypsum board drilling equipment designed for precision perforation in various building materials.
Product Specifications
Pressure 80T, 160T, 200T
Usage Gypsum Board, MDF, HPL, Fiber cement board perforation
Holes Round, Square
Automatic Level High automatic
Thickness Max. 20mm
Technical Specifications
  • Punching pressure: 200 ton
  • Stroke: 30 mm
  • Max mold height closed: 260mm
  • Number of strokes: 50 times/minute
  • Slide surface: 210*1100mm
  • Working table: 300*1670mm
  • Spacing of both pole: 1350mm (load the max board width 1220mm)
  • Power of main motor: 22kw
  • Power of servo motor: 2.6kw (brand: Zhejiang yifeng)
  • Feeding accuracy: ±1mm
  • Maximum feeding rate: 100mm
  • Maximum feeding thickness: 20mm
  • Gross weight of machine: 11000kg
  • Overall dimension: 2300*1500*2300(H*L*W)
Applications
This perforation machine is designed for creating holes in various materials including gypsum ceiling board, MgO board, MDF, HPL, Fiber cement board, and metal sheets. Custom hole shapes are available to meet specific requirements. Comprehensive operational training is provided.
